Surface-mounted automatic hand dryer
Women's clothing size
| Size | XS | S | M | L |
|---|---|---|---|---|
| Euro | 32/34 | 36 | 38 | 40 |
| USA | 0/2 | 4 | 6 | 8 |
| Bust(in) | 31-32 | 33 | 34 | 36 |
| Bust(cm) | 80.5-82.5 | 84.5 | 87 | 92 |
| Waist(in) | 24-25 | 26 | 27 | 29 |
| Waist(cm) | 62.5-64.5 | 66.5 | 69 | 74 |
| Hips(in) | 34-35 | 36 | 37 | 39 |
| Hips(cm) | 87.5-89.5 | 91.5 | 94 | 99 |
With your arms relaxed at your sides, measure around the fullest part of your chest.
Measure around the narrowest part of your natural waist, generally around the belly button. To ensure a comfortable fit, keep one finger between the measuring tape and your body.
SPECIFICATIONS :
Seam welded stainless steel warm air high-speed hand dryer.
Uniquely designed to have a sound pressure level of 70 dB(A) measured at 39″ (1 meter) from source.
ADA compliant with less than 4″ protrusion from the wall.
CULus-listed and CE-marked.
115v, 8.2 AMP, 50/60 Hz, 1000 Watts, cULus Listed and CE Marked.
230v, 4.0-4.4 AMP, 50/60 Hz, 1000 Watts, cULus Listed and CE Marked.
Width : 11-11/16″ (297mm)
Height : 13-7/16″ (342mm)
Depth : 3-15/16″ (100mm)
Control System : Automatic, infrared, no-touch.
Product Specs :
Finish : Satin-Finish Stainless Steel
Material : Stainless Steel
Mounting Options : Surface Mounted
Accessibility : ADA Compliant
Data sheet
- Type of product
- Hand dryer
- Reference
- B-7179
- Product width (in mm)
- 297
- Product height (in mm)
- 342
- Depth (in mm)
- 100
- Installation type
- Wall-mounted ·✓
